SpecificationDetails / Value
Dimensions ( L x W x H )140 x 150 x 86mm
Cybenetics RatingGOLD
80 Plus RatingGOLD
A T X VersionIntel ATX 12V v3.1
ProtectionsOVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP
P F C0.99
Input Voltage100-240V
Input Current850W: 12A750W: 10A650W: 10A
Input Frequency47Hz-63Hz
D C Output Voltage+5V | +3.3V | +12V | -12V | +5Vsb
Total Output850W: +5V/+3.3V : 22A, +12V : 70.8A, -12V : 0.3A, +5Vsb : 3A750W: +5V/+3.3V : 22A, +12V : 62.5A, -12V : 0.3A, +5Vsb : 3A650W: +5V/+3.3V : 20A, +12V : 54.1A, -12V : 0.3A, +5Vsb : 3A
Power Excursion850W: 1997W (*up to 235% of the PSU's rated power for 100μs)750W: 1762W (*up to 235% of the PSU's rated power for 100μs)650W: 1527W (*up to 235% of the PSU's rated power for 100μs)
Fan Size120mm FDB Fan
Fan BearingFDB (Fluid Dynamic Bearing)
Fan Speed2400 RPM
M T B F100K hours at full load
A T X 24 Pin Connector1
E P S 8 Pin Connector2
P C I E 6+2 Pin Connector850W / 750W: 3650W: 2
Molex 4 Pin Connector2
12 V 2x6 (12+4) Connector850W / 750W (600W): 1650W (450W): 1
CertificationCB / CE / FCC / TUV / cTUVus / BSMI / CCC NOM / FCC IC / UKCA / TUV / TUV S-Mark / cTUVus
Weight850W / 750W: Product + Cables: 1450g + 1350g, Package: 3.03kg650W: Product + Cables: 1450g + 1320g, Package: 3kg
Warranty7 Years
850 W1997W (up to 235% of the PSU's rated power for 100μs)
750 W1762W (up to 235% of the PSU's rated power for 100μs)
650 WProduct + Cables: 1450g + 1320g, Package: 3kg
850 W / 750 WProduct + Cables: 1450g + 1350g, Package: 3.03kg
850 W / 750 W (600 W)1
650 W (450 W)1
wattage750W
