BrandHAVN
ModelHS 420
TypeMid Tower
ColorBlack
Case MaterialSGCC sheet metal, tempered glass, ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets
With Power SupplyNo
Motherboard CompatibilityE-ATX (up to 277 mm), ATX, Micro-ATX, Mini-ITX
Side Panel WindowUniSheet heat-formed tempered glass (front and side)
Dust FiltersTop (built-in), Right (built-in), Bottom (removable), Rear bottom (removable)
Internal 3.5" Drive Bays4
Internal 2.5" Drive BaysUp to 8 (shared with 3.5" bays)
Expansion Slots6
Front Ports1 × USB 3.2 Gen 2 Type-C, 2 × USB 3.2 Gen 1 Type-A, 1 × Audio Jack, Power & Reset Buttons
Fan OptionsTop: 3 × 120mm / 3 × 140mm Right: 3 × 120mm / 3 × 140mm Bottom: 3 × 120mm / 3 × 140mm Rear: 2 × 120mm / 2 × 140mm (up to 30mm thick)
Radiator OptionsTop: 280 / 360 / 420 mm (up to 65mm thick, no RAM overlap) Right: 280 / 360 / 420 mm (60–80mm depending on GPU) Bottom: 280 / 360 / 420 mm (up to 120mm thick)
Max G P U LengthUp to 480 mm
Max C P U Cooler HeightUp to 185 mm
Max P S U LengthUp to 220 mm (290 mm clearance)
Dimensions ( H x W x D)547 × 259.5 × 541 mm
FeaturesDual-chamber hybrid structure, panoramic tempered glass, SimpliCable routing, integrated fan hub (12 channels), internal VESA mount for up to 14" display, GPU holder, supports up to 11 fans, optimized airflow and cooling flexibility.
Package ContentHAVN HS 420 Case, accessory kit, GPU holder, user manual.
