MOTHERBOARDGIGABYTEمتوفر
Gigabyte B850M GAMING X WIFI6E Motherboard
المواصفات
SpecDetail
BrandASUS
ModelB850M GAMING X WIFI6E (B850M GAMING X WF6E)
ChipsetAMD B850
SocketAMD Socket AM5
Form FactorMicro-ATX (mATX)
Supported ProcessorsAMD Ryzen 9000 Series / Ryzen 8000 Series / Ryzen 7000 Series
X3 D Turbo ModeYes — single-click FPS performance boost for Ryzen X3D & non-X3D CPUs
Power Phases10+2+2 Twin Digital VRM (5+5 parallel phase design)
P C B6-Layer, Mid-Loss, 2× Copper PCB
ThermalVRM Thermal Armor Advanced — 5 W/mk thermal pad
Power Connector24-pin ATX + 8-pin CPU with UD Solid Pin
مقارنة الأسعار
المتجرالسعرالتوفر
highendstore
٩٬٧٠٠ جنيهمتوفرزيارةturbo-computer
٩٬٨٠٠ جنيهمتوفرزيارةSigma Computer
٩٬٨٠٠ جنيهمتوفرزيارةturbo-computer
٩٬٨٠٠ جنيهمتوفرزيارةSlots
4× DDR5 DIMM — Dual Channel
Max Capacity256 GB (64 GB per single DIMM)
Supported SpeedsDDR5 4400 / 4800 / 5200 native — OC up to 8200 MT/s
O C ProfilesAMD EXPO and Intel XMP supported
E C CNon-ECC Un-buffered DIMM
H D M I1× HDMI 2.1 — max resolution 4096×2160 @ 60Hz, HDCP 2.3, HDR
M.2 Slot 1 ( C P U)1× PCIe 5.0 M.2 — Socket 3, M-Key, type 2580/25110
M.2 Slot 2 ( Chipset)1× PCIe 4.0 M.2 — Socket 3, M-Key, type 2580/25110
S A T A Ports4× SATA 6Gb/s
R A I DRAID 0, RAID 1, RAID 10
P C Ie x16 ( C P U)1× PCIe 5.0 x16 — PCIe UD Slot (reinforced stainless steel)
P C Ie x16/x4 ( Chipset)1× PCIe 3.0 running at x4
U S B C ( Back Panel)1× USB Type-C — USB 3.2 Gen 2 (CPU)
U S B 3.2 Gen 2 Type A ( Back Panel)1× USB 3.2 Gen 2 Type-A (red, CPU)
U S B 3.2 Gen 1 ( Back Panel)2× USB 3.2 Gen 1 (Chipset)
U S B 2.0 ( Back Panel)4× USB 2.0/1.1 (CPU + USB 2.0 Hub)
U S B Internal Headers1× USB-C Gen 2 header / 1× USB 3.2 Gen 1 header / 2× USB 2.0 headers
Wi FiWi-Fi 6E (802.11ax, 2.4/5/6 GHz tri-band)
BluetoothYes (included with Wi-Fi module)
Audio CodecRealtek HD Audio
Channels2 / 4 / 5.1 / 7.1-channel
Audio Jacks ( Rear)3× audio jacks
Fan Headers4× PWM/DC fan headers (1× CPU fan, 1× CPU/pump, 1× SYS fan, 1× SYS/pump)
Fan ControlSmart Fan 6 — Dual Fan Curve Mode
A R G B Headers3× Addressable RGB Gen2 + 1× RGB LED strip header
Q Flash PlusYes — auto scan BIOS file, flash without CPU/RAM/GPU installed
P O S T L E DsStatus LEDs for CPU, memory, GPU, and OS
O S SupportWindows 10 64-bit / Windows 11 64-bit
Software@BIOS, EasyTune, RGB Fusion, Smart Backup, System Information Viewer
https//www.gigabyte.com/Motherboard/B850M-GAMING-X-WIFI6E-rev-10
