ChipsetAMD B850
SocketAM5
Form FactorMicro-ATX
C P U SupportAMD Ryzen 9000 / 8000 / 7000 Series
TypeDual Channel DDR5
Slots4 x DIMM
Max CapacityUp to 256 GB
SpeedsSupports up to DDR5 8200 (OC)
ProfilesSupports AMD EXPO and Intel XMP memory modules
P C Ie Slots1 x PCIe 5.0 x16 (Primary graphics card slot)1 x PCIe 3.0 x4
M.2 Slots ( S S D)1 x M.2 supporting PCIe 5.0 x41 x M.2 supporting PCIe 4.0 x4
S A T A4 x SATA 6Gb/s connectors
V R M Design8+2+2 Twin Digital VRM phases for stable power delivery.
ThermalsHeatsinks for MOSFETs and an M.2 Thermal Guard for the primary SSD.
Fan HeadersSupports PWM/DC fans and water cooling pump configurations.
Video Outputs1 x HDMI 2.1, 2 x DisplayPort 1.4
U S B Ports1 x USB 3.2 Gen 2 Type-C1 x USB 3.2 Gen 2 Type-A2 x USB 3.2 Gen 14 x USB 2.0
NetworkingRealtek 2.5GbE LAN
AudioRealtek Audio CODEC (7.1 Channel support)
Q Flash PlusDedicated button to update BIOS without installing CPU, RAM, or GPU.
Next Gen ReadyFeatures PCIe 5.0 for both the primary GPU slot and one M.2 slot to handle ultra-fast data speeds.
E Z LatchSimplifies hardware installation with tool-less mechanisms for PCIe and M.2 components.
Performance TuningIncludes specialized BIOS modes like "X3D Turbo Mode" to maximize gaming performance on compatible Ryzen processors.
socketAM5
memory TypeDDR5
chipsetB850M
