ModelGIGABYTE B760M AORUS ELITE GEN5
C P U SupportIntel® 14th/13th/12th Gen Core™, Pentium® Gold, and Celeron® Processors (LGA1700 Socket)
ChipsetIntel B760 Express
D I M M Slots4 x DDR5 DIMM sockets
Max Memory supportUp to 256GB (DDR5 7800(O.C.))
P C I- E Slots1 x PCIe 5.0 x16, 1 x PCIe 4.0 x4
M.2 Slots2 x M.2 PCIe 4.0 x4/x2
S A T A I I I4 x SATA 6Gb/s ports
A R G B Headers3 x ARGB Gen2
R G B Headers1 x RGB
Fan Headers1 x CPU, 3 x System
Front Type C Headers1 x USB 3.2 Gen 2 Type-C
Front U S B 3 Headers1 x USB 3.2 Gen 1 header
U S B 2.0 Headers2 x USB 2.0/1.1 headers
Flash B I O S Buttons1 x Q-Flash Plus button
Clear C O M S Buttons1 x Clear CMOS jumper
Onboard Graphics Outputs1 x HDMI 2.1, 1 x DisplayPort 1.2
U S B Ports3 x USB 3.2 Gen 1, 4 x USB 2.0/1.1, 1 x USB 3.2 Gen 2 Type-A
U S B Type C Ports1 x USB 3.2 Gen 2x2 Type-C (rear), 1 x USB 3.2 Gen 2 Type-C (front)
Ethernet L A N PortRealtek 2.5GbE LAN
Audio Jacks2 x audio jacks
Optical1 x S/PDIF Out
Operating SystemWindows 11 64-bit, Windows 10 64-bit
Form FactorMicro ATX (24.4cm x 24.4cm)
socketLGA1700
memory TypeDDR5
chipsetB760M
